30 mins Fire Rated Doors – FW30 Model

Single or Double-leaf Fire Door model FW30 is a 30 min fire rated door, meeting with Israeli and International fire regulations, providing outstanding protection for various types of commercial and residential buildings, industries and institutions.

Technical specification

  • General Description: Door leaf with two 0.8mm thick galvanized steel casings and interior reinforcements, intumescing gasket between door and frame. Fire rated hardware& telescopic bottom insert for final height adjustment.
  • Hardware & Accessories :
    Anti -Panic Lock
    Moveable lever door handles / Fixed handle
    Panic bar or Push bar – optional
    Hydraulic closer – optional
    Door closing coordinator for double door.
  • Window Dimensions (optional): 600×400 mm 820×170 mm  * Round 440mm diameter
  • Door Finish: PVC finish or powder coating.
  • Dimensions: Maximum door leaf height (without bottom insert) – 2200 mm * Maximum door frame height – 2400 mm * Maximum moveable door width – 1140 mm * Maximum fixed door width – 1140 mm Maximum double-leaf door frame width – 2360 mm *
