90 mins Fire Rated Entry Door 414 OXFORD MODEL

The 414 SERIES is designed to meet or exceed NYC Department of Buildings Code Requirements and is a certified UL 90 Minute Fire Rated steel door according to UL 10C and NFPA 252.

Technical specification

  •  Two 18 gauge galvanized steel sheet covers
  •  Interior steel bar reinforcement for optimum security
  •  Double layered high-density rockwool insulation and fire resistant gypsum board  2” thick door leaf
  •  132 lbs. UL door leaf
  •  Rebated door leaf for extra acoustic and security protection
  •  Integrated gasket and edge sealing materials along three sides
  •  Integrated weather stripping along the bottom


  •  Model RB507 4-way Multi-point Locking System  Four front lock bolts and spring loaded latch
  •  Reinforced bottom and upper bolts
  •  Hook-like rear fixed bolts
  •  RB’s patented high security tamper proof cylinder  Security cover plates on both sides

*The Gladiator System upgrade is available for this model FRAME

  •  16 gauge galvanized steel single or double rebated knockdown frame


  • Standard height from 80” up to 96” • Standard width from 24” to 36”
